We offer the installation of the plates inclusive the grouting. Our assembly people do the mounting of base plates, measurement tables and test rig plates all over the world.

Lifting and transport devices, grout pumps and all kinds of measurement equipment such as Laser can be provided to reach perfect installations with best possible accuracy's. (installation instructions)

Base plate installations complete with Seismic mass and vibration isolation.

We offer the design and built of complete seismic mass and floor plate combinations including anchorframe construction and possible vibration isolation via air-, visco- or steel springs from our own manufacturing.

We provided nearly all seismic mass designs and constructionc in Europ's Test R&D centers. Contact your subsidiary or ask us for a reference list.

(left) 600 to Seismic mass on CFM-Schiller GRB air springs. Natural frequency approx. 1.2 Hz

Grouting Services

ITBONA Inc. recommends Pagel, worldwide leading manufacturer of non-shrinking grouts. For more than 25 years PAGEL SPEZIAL-BETON GmbH & Co. KG in Essen has influenced and played a major role in the development of grouts and special mortars. The PAGEL-GROUTING-SYSTEM has become a worldwide recognized system for grouting and our products like V1, V12 and V13 are synonymous with the word "non-shrinking-grout".

A wide range of products together with an undeviating quality backed by a comprehensive customer service has earned PAGEL its outstanding reputation for being able to provide a product and solution for factory and industrial machine foundations.

Many years of this reputation and excellent quality has resulted in PAGEL being certified with the EN ISO 9001.

For more information on PAGEL products in the US please visit PAGEL-USA at www.pagel-usa.com
